Description
Construction：
Tough polyester cords won’t fatique, even with repeated shock loads. Cords are specially treated to resist stretch and carry high horsepower loads. Aramid cords are also available.
Transversely aligned fiber reinforcement in the belt cogs assures crosswise rigidity and flexibikity to reduce heat build up and minimize cracking
Polychloroprene impregnated high modulus fabric for higher flexibility
Product Dimensions:
| Section | Top Width mm |
Thickness mm |
Production Range mm |
| 20×12.5 | 20 | 12.5 | 500-6500 |
| 25×14 | 25 | 14 | 500-6500 |
| 25×16 | 25 | 16 | 500-6500 |
| 32×16 | 32 | 16 | 500-6500 |
| 34×10 | 34 | 10 | 500-6500 |
| 35×16 | 35 | 16 | 500-6500 |
| 36×14 | 36 | 14 | 500-6500 |
| 38×18 | 38 | 18 | 500-6500 |
| 40×13 | 40 | 13 | 500-6500 |
| 40×20 | 40 | 20 | 500-6500 |
| 40×26 | 40 | 26 | 500-6500 |
| 45×20 | 45 | 20 | 500-6500 |
| 50×20 | 50 | 20 | 500-6500 |
| 55×22 | 55 | 22 | 500-6500 |
| 55×25 | 55 | 25 | 500-6500 |
| 52×16 | 52 | 16 | 500-6500 |
| 56×26 | 56 | 26 | 500-6500 |
| 60×25 | 60 | 25 | 500-6500 |
| 68×24 | 68 | 24 | 500-6500 |
| 71×26 | 71 | 26 | 500-6500 |
| 76×26 | 76 | 26 | 500-6500 |
| HG | 16.5 | 8 | 500-6500 |
| HH | 20.4 | 10 | 500-6500 |
| HI | 25.4 | 12.7 | 500-6500 |
| HJ | 31.8 | 15.1 | 500-6500 |
| HDJ | 33 | 18.5 | 500-6500 |
| HK | 38.1 | 17.5 | 500-6500 |
| HL | 45 | 19.8 | 500-6500 |
| HM | 50.8 | 22.2 | 500-6500 |
| HN | 57.2 | 23.9 | 500-6500 |
| HO | 63.5 | 25.4 | 500-6500 |
Features:
Smooth running
Improved flexibility due to the specially-woven canvas
Longer service life, about 2 times than traditional belts
Absorb Shock Loads & Large Lateral Pressure
High Power Transmission
High Tensile Strength
Cut edge cogged belt with polyester or aramid cord
Temperature Range:
-18 to 90℃ for regular belts
-25 to 100℃ for special requirement belts
Applications:
Large agricultural machinery, such as tractors, combine harvesters and rice planting machinery
Length range: 500-6500mm
Reference standard:
ASAE 211.4, BS 3790, DIN 2215, RMA IP 22, ISO 4184, IS 2494, ISO 5289, IS 11038, ISO 3410
